Factory Price Hot Selling Thermal Conductive Silicon Pad1.5W 0.5~5.0mm Thick Thermal Gap Filler Pad For Car Battery

Çin Dongguan Ziitek Electronic Materials & Technology Ltd. Sertifikalar
Çin Dongguan Ziitek Electronic Materials & Technology Ltd. Sertifikalar
Termal İletkenlik Pedi, çok iyi çalışıyor ve çalışıyor. Artık diğer Termal İletken Pad'e ihtiyacımız yok!

—— Peter Goolsby

2 yıldır Ziitek ile işbirliği yaptım, yüksek kaliteli termal iletken malzemeler sağladılar ve zamanında teslim ettiler, faz değişim malzemelerini tavsiye ettiler

—— Antonello Sau

Kaliteli, iyi hizmet. Ekibiniz bize her zaman yardım eder ve çözer, her zaman iyi bir partner olacağımızı umarız!

—— Chris Rogers

Ben sohbet şimdi

Factory Price Hot Selling Thermal Conductive Silicon Pad1.5W 0.5~5.0mm Thick Thermal Gap Filler Pad For Car Battery

Factory Price Hot Selling Thermal Conductive Silicon Pad1.5W 0.5~5.0mm Thick Thermal Gap Filler Pad For Car Battery

Büyük resim :  Factory Price Hot Selling Thermal Conductive Silicon Pad1.5W 0.5~5.0mm Thick Thermal Gap Filler Pad For Car Battery

Ürün ayrıntıları:
Menşe yeri: ÇİN
Marka adı: ZIITEK
Sertifika: UL and RoHs
Model numarası: TIF100-02F Serisi
Ödeme & teslimat koşulları:
Min sipariş miktarı: 1000 pcs
Fiyat: Anlaşılabilir
Ambalaj bilgileri: 1000pcs/çanta
Teslim süresi: 3-5 iş günü
Yetenek temini: 100000 pc/gün
Detaylı ürün tanımı
Ürünler Adı: Fabrika Fiyatı Sıcak Satış Termal İletken Silikon PAD1.5W 0.5 ~ 5.0mm Kalın Termal Boşluk Dolgu Padi Sertlik: 60 Shore 00
Başvuru: Araç Pili ve Güç Kaynağı Kalınlık: 0.020 "(0.5mm) ~ 0.200" (5.0mm)
Termal iletkenlik: 1,5 W/mK Sürekli kullanım sıcaklığı: -45 ila 200°C
Renk: Gri Anahtar Kelimeler: termal boşluk dolgu pedi
Örnek: Örneksiz

Factory Price Hot Selling Thermal Conductive Silicon Pad1.5W 0.5~5.0mm Thick Thermal Gap Filler Pad For Car Battery



The TIF®100-02F Series is recommended for applications that require a minimum amount of pressure on components. The viscoelastic nature of the material also gives excellent low-stress vibration dampening and shock absorbing characteristics. Ziitek TIF®100-02F is an electrically isolating material, which allows its use in applications requiring isolation between heat sinks and high-voltage, bare-leaded devices.


Features


> Good thermal conductive: 1.5W/mK
> Moldability for complex parts
> Soft and compressible for low stress applications
> High tack surface reduces contact resistance
> Easy release construction
> Electrically isolating
> High durability


Applications


> Cooling components to the chassis of frame
> High speed mass storage drives
> Heat Sinking Housing at LED-lit BLU in LCD
> LED TV and LED-lit lamps
> RDRAM memory modules
> Micro heat pipe thermal solutions
> Automotive engine control units
> Telecommunication hardware

> Handheld portable electronics
> Semiconductor automated test equipment (ATE)
> CPU

> Display card

> Power supply
> Heat pipe thermal solutions
> Memory Modules

Typical Properties of TIF®100-02F Series
Property Value Test method
Color Gray ******
Construction &Compostion Ceramic filled silicone elastomer ******
Thickness range 0.020"(0.5mm)~0.200"(0.50mm) ASTM D374
Specific Gravity 2.3g/cc ASTM D297
Hardness 60 Shore 00 ASTM 2240
Continuos Use Temp -45 to 200℃ ******
Dielectric Breakdown Voltage > 5500 VAC ASTM D149
Dielectric Constant 4.0 MHz ASTM D150
Volume Resistivity 1.0 X1012 Ohm-meter ASTM D257
Flame rating 94 V0 UL E331100
Outgassing(TML) 0.35% ASTM E595
Thermal conductivity 1.5 W/m-K ASTM D5470



Product Specification

Product Thicknesses: 0.020-inch to 0.200-inch (0.5mm to 5.0mm)
Product Sizes:8" x 16"(203mm x406mm)

Individual die cut shapes and custom thickness can be supplied, Please contact us for comfirming.

Factory Price Hot Selling Thermal Conductive Silicon Pad1.5W 0.5~5.0mm Thick Thermal Gap Filler Pad For Car Battery 0

Packaging Details & Lead time



The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized



Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated



Company profile



Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.



Factory Size:8000~10,000 square meters

Factory Country/Region:No.12, Xiju Road, Hengli Township, Dongguan City, Guangdong Province, P.R.China

Online-service : 12 hours , Inquiry reply within fastest.
Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8).

Well-trained & experienced staff are to answer all your inquiries in English of course.

Standard Export Carton Or Marked With Customer's Information Or Customized.

Provide free samples



After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof.

we will help you to deal with it and give you satisfactory solution.
