Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS

Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS

Büyük resim :  Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS

Ürün ayrıntıları:
Menşe yeri: Çin
Marka adı: Ziitek
Sertifika: RoHs
Model numarası: TIG780-50HP
Ödeme & teslimat koşulları:
Min sipariş miktarı: 1 kg
Fiyat: 0.1-10 USD/KG
Ambalaj bilgileri: 1kg/kutu
Teslim süresi: 3-5 iş günü
Yetenek temini: 100 kg/gün
Detaylı ürün tanımı
Ürün adı: Elektronik Bileşenler IC, CPU, MOS için İyi Isı İletkenliği Termal Gres Termal Macunu Renk: Gri
İnşaat ve Kompozisyon: Metal oksit/silikon yağı Yoğunluk: 2,3 gr/cm³
Isı İletkenliği: 5.0 w/mk Termal empedans((%22C-in²/W) @30 psi): 0,015
Anahtar Kelimeler: Termal Macun Önerilen çalışma sıcaklığı: -40 ~ 200 ℃

Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS



TIG®780-56 Series is an environmentally friendly silicone based thermal paste designed to efficiently solve overheating problems in electronic devices and improve long-term reliability, TIG®780-50HP is a paste like material that can fully wet the surfaces of electronic components and heat sinks. It acts to fill the gaps between electronic components and heat sinks, eliminate air, and significantly improve heat dissipation eficiency (better than traditional thermal pads or ordinary silicone grease), thereby forming an extremely low thermal resistance interface and achieving excellent thermal conductivity efficiency.



Features



> High thermal conductivity
> Excellent low thermal resistance
> Good electrical insulation
> Excellent long-term stability
> Non toxic, environmentally friendly,and safe, meeting RoHS requirements


Applications lnclude


> Al server
> Industrial equipment
> Medical electronic devices
> LED TV,LED lighting fixtures
> Automotive Electronics (New Energy and Intelligence)
> High end consumer electronics and portable devices



Typical Properties of TIG®780-50HP Series
Property Value Test Method
Color Gray Visual
Construction &Compostion Metal oxide / Silicone oil Ziitek Test Method
Density 2.30 g/cm³ ASTM D792
Thermal Conductivity 5.0W/mK ASTM D5470
Bond line Thickness (mm) 0.008 ASTM D374
Thermal Impedance (℃·in²/W) @30 psi 0.015 ASTM D5470
Thermal Impedance (℃·in²/W) @50 psi 0.012 ASTM D5470
Recommended Operating Temp -40℃ to 200℃ *****
Viscosity(mPa.s) 200000 GB/T 10247



Packaging Specifications


Packaging specifications: 0.5kg,1kg,2kg;

If you have any other specification requirements, please contact our company.



Good Thermal Conductivity Thermal Grease Thermal Paste For Electronic Components IC, CPU, MOS 0
